DS3231 RTC Module Precise Real Time Clock I2C AT24C32 without cell
Accurately keep track of time with our DS3231 RTC Module, a precise real-time clock module that utilizes I2C communication. This module includes an AT24C32 EEPROM for additional data storage. Please note that this module does not come with a battery, so you'll need to provide a backup power source for the RTC to function when the main power is off.
Specifications:
- Clock Chip: DS3231 (highly accurate RTC)
- EEPROM: AT24C32 (32K I2C EEPROM)
- Communication: I2C interface
- Operating Voltage: 3.3V to 5V DC
- Current Consumption: Low power consumption (typically 200µA in operation)
- Timekeeping Accuracy: ±2ppm from 0°C to +40°C
- Operating Temperature: -40°C to +85°C (-40°F to +185°F)
- Dimensions: Compact PCB module
Features:
- Highly accurate timekeeping
- Integrated temperature-compensated crystal oscillator
- Includes 32K EEPROM for additional data storage
- I2C interface for easy integration with microcontrollers
- Requires external battery for backup power
Applications:
- Real-time clock applications
- Data logging and timestamping
- Embedded systems and automation
- Robotics and IoT projects
- Time-based event triggering
